2022-11-05

0047 文字卡片-Templater

效果展示

2022-11-03 Thur. 07_19_23.png

有点大，被放大了会显得不那么精致，其实还行啦，我主要是用在微信群里吸引眼球，因为你直接发一大段文字大概率没人读。

这个东西不完美，但是能用，所以如果你想用，请先完整阅读说明。

代码

Scripts/get_tweet_card.js

就是 Templater 的脚本文件夹里。

/** @type {object} 一些设定，可以修改，但不推荐 */
const opt = {
  width: 720,
  margin: 60,
  padding: 48,
  fontSize: 36,
  lineHeight: 54,
  indent: 72,
  paragraphsMarginBottom: 18,
  fontFamily: 'Menlo, SFMono-Regular, Consolas, "Roboto Mono", "Source Code Pro", ui-sans-serif, -apple-system, BlinkMacSystemFont, "Segoe UI", Roboto, "Inter", "Apple Color Emoji", "Segoe UI Emoji", "Segoe UI Symbol", "Microsoft YaHei", sans-serif'
}
/** 基于上方属性计算得出 */
opt.cardWidth = opt.width - opt.margin*2
opt.contentWidth = opt.cardWidth - opt.padding*2
opt.logoSize = 2*opt.fontSize
opt.paddingLR = opt.padding
opt.paddingTB = opt.padding
opt.marginLR = opt.margin
opt.marginTB = opt.margin
opt.smallFontSize = opt.fontSize * 0.6
opt.contentMarginLR = opt.marginLR+opt.paddingLR
opt.contentMarginTB = opt.marginTB+opt.paddingTB

/**
 * 数字两位化
 *
 * @param {number} num 0~99 的整数
 * @returnn {string}
 */
const dbNum = num => (num > 9 ? String(num) : '0' + num);
/** @type {array} */
const daysName = ['Sun.', 'Mon.', 'Tues.', 'Wed.', 'Thur.', 'Fri.', 'Sat.']
/**
 * 获取当前时间字符串
 *
 * @return {string}
 */
const getNowTime = () => {
  const now = new Date()
  const t = {
    YYYY : now.getFullYear(),
    MM: dbNum(now.getMonth()+1),
    DD: dbNum(now.getDate()),
    hh: dbNum(now.getHours()),
    mm: dbNum(now.getMinutes()),
    ss: dbNum(now.getSeconds()),
    EE: daysName[now.getDay()]
  }
  return `${t.YYYY}-${t.MM}-${t.DD} ${t.EE} ${t.hh}:${t.mm}:${t.ss}`
}
// 创建画布对象
const canvas = document.createElement('canvas')
const ctx = canvas.getContext('2d')

/**
 * 画布文字逐行分割
 *
 * @param {object} ctx 画布上下文对象
 * @param {string} text 要写入的文字内容
 * @param {number} width 文字内容在画布中占据的宽度
 * @return {array} 二维数组，第1层是段落，第2层是段落中的每一行
 */
const canvasTextSplit = (text, width) => {
  text = text.trim()
  if(text.length === 0) return []
  const result = []
  // 先进行段落的分割
  const paragraphArray = text.replace(/(\r?\n\s*)+/g, '\n').split(/\s*\r?\n\s*/g)
  for(const p of paragraphArray){
    const linesInParagraph = []
    let nowLetter = 0
    for (let i = 0; i <= p.length; i++) {
      const thisLineWidth = linesInParagraph.length ? width : width-opt.indent
      if (ctx.measureText(p.substring(nowLetter, i)).width > thisLineWidth) {
        linesInParagraph.push(p.substring(nowLetter, i-1))
        nowLetter = i-1
      }else if(i === p.length){
        linesInParagraph.push(p.substring(nowLetter, i))
      }
    }
    result.push(linesInParagraph)
  }
  return result
}
/**
 * 将段落数组中的文字绘制到画布
 *
 * @param {object} ctx 画布上下文对象
 * @param {array} paragraphs 二维数组，第1层是段落，第2层是段落中的每一行
 * @param {number} startX 起始的横坐标
 * @param {number} startY 起始的纵坐标
 * @param {number} opt.lineHeight 行高
 * @return {number} 结束位置的纵坐标
 */
const drawText = async(paragraphs, startX, startY) => {
  let thisLineY = startY
  paragraphs.forEach((p, pIndex) => {
    p.forEach((line, lIndex)=>{
      const thisLineX = lIndex ? startX : startX + opt.indent
      thisLineY += opt.lineHeight
      ctx.fillText(line, thisLineX, thisLineY)
    })
    thisLineY += opt.paragraphsMarginBottom
  })
  return thisLineY
}
/**
 * 计算绘制文字所需要占据的高度
 *
 * @param {array} paragraphs 二维数组，第1层是段落，第2层是段落中的每一行
 * @param {number} opt.lineHeight 行高
 * @return {number} 文字内容所占据的高度
 */
const textNeedHeight = (paragraphs)=>{
  return (paragraphs.length-1) * opt.paragraphsMarginBottom
        + paragraphs.flat().length * opt.lineHeight
}
/**
 * 将 base64 格式的图片转换为 Blob 格式数据
 *
 * @param {string} dataUrl base64 格式的数据地址
 * @return {object} Blob 格式的图片数据
 */
const dataURLtoBlob = dataUrl=>{
  const dataArr = dataUrl.split(',');
  const mime = dataArr[0].match(/:(.*?);/)[1];
  const bStr = atob(dataArr[1]);
  let n = bStr.length;
  const uint8Arr = new Uint8Array(n);
  while(n--){
      uint8Arr[n] = bStr.charCodeAt(n);
  }
  return new Blob([uint8Arr], {type:mime});
}
/**
 * 将画布保存为图片并自动进行下载
 *
 * @param {object} canvas 画布对象
 * @param {string} name 保存的文件名
 * @param {string} [type="png"] 文件图片的格式: png、jpeg、gif
 */
const downloadImgFromCanvas = (name, type="png")=>{
  if(type==='jpg') type = 'jpeg'
  const imgDataUrl = canvas.toDataURL('image/'+type)
  // const imgData = canvas.toDataURL({format: 'png', quality:1, width:20000, height:4000})
  const blob = dataURLtoBlob(imgDataUrl)
  const blobUrl = URL.createObjectURL(blob)

  const imgDownloadLink = document.createElement('a')
  imgDownloadLink.download = name+'.'+(type==='jpeg' ? 'jpg' : type)
  imgDownloadLink.href = blobUrl
  imgDownloadLink.click();
}
/**
 * 重置画布对象
 *
 * @param {number} height 画布的高度
 * @param {string} fillColor 画布填充的背景颜色
 */
const canvasRest =(height, fillColor)=>{
  canvas.width = opt.width
  canvas.height = height
  ctx.fillStyle = fillColor
  ctx.fillRect(0, 0, canvas.width, canvas.height)
}

/**
 * 绘制圆角矩形
 *
 * @param {number} x
 * @param {number} y
 * @param {number} w
 * @param {number} h
 * @param {number} r
 */
const drawRoundedRect = (x, y, w, h, r)=>{
  var ptA = { x: x + r, y: y }
  var ptB = { x: x + w, y: y }
  var ptC = { x: x + w, y: y + h }
  var ptD = { x: x, y: y + h }
  var ptE = { x: x, y: y }

  ctx.beginPath();

  ctx.moveTo(ptA.x, ptA.y);
  ctx.arcTo(ptB.x, ptB.y, ptC.x, ptC.y, r);
  ctx.arcTo(ptC.x, ptC.y, ptD.x, ptD.y, r);
  ctx.arcTo(ptD.x, ptD.y, ptE.x, ptE.y, r);
  ctx.arcTo(ptE.x, ptE.y, ptA.x, ptA.y, r);

  ctx.closePath()
  // ctx.stroke();
  ctx.fill()
}

const loadImage = (url, l, t) => new Promise( resolve => {
  const img = new Image()
  img.onload = () => {
    ctx.drawImage(img, l, t, opt.logoSize, opt.logoSize)
    return resolve(true)
  }
  img.src = url
});

const bgGradient = ctx.createLinearGradient(0, 0, opt.width, opt.width/8);
bgGradient.addColorStop(0, "#ffafbd");
bgGradient.addColorStop(1, "#ffc3a0");

/**
 *
 *
 * @param {*} tp
 * @return {*}
 */
async function get_tweet_card(tp, logo='', name='稻米鼠', userId='@Dao_Mouse'){
  /** @type {string} 获取输入 */
  const inputContent = await tp.system.prompt('输入内容', '', false, true)
  if(!inputContent) return ''

  ctx.font = 'normal '+opt.fontSize+'px '+opt.fontFamily
  ctx.textAlign = "left"
  ctx.fillStyle = "#333336"
  /** 整理内容，计算尺寸 */
  const contentArr = canvasTextSplit(inputContent, opt.contentWidth)
  opt.contentHeight = textNeedHeight(contentArr)
  opt.cardHeight = opt.contentHeight
                  + opt.padding*2
                  + opt.logoSize
                  + opt.lineHeight /** 用来书写时间 */
                  + 2*opt.paragraphsMarginBottom /** 放在内容上下 */
  /** 初始化画布 */
  ctx.shadowBlur = 0
  ctx.shadowColor = "rgba(0,0,0,0)"
  canvasRest(opt.cardHeight+2*opt.marginTB, bgGradient)
  ctx.shadowOffsetX = 0
  ctx.shadowOffsetY = 0
  ctx.shadowBlur = opt.margin*0.6
  ctx.shadowColor = "rgba(0, 0, 0, .3)"
  ctx.fillStyle = 'rgba(255, 255, 255, .8)'
  drawRoundedRect(opt.marginLR, opt.marginTB, opt.cardWidth, opt.cardHeight, 18)

  ctx.font = 'normal '+opt.fontSize+'px '+opt.fontFamily
  ctx.textAlign = "left"
  ctx.fillStyle = "#333336"
  ctx.shadowBlur = opt.fontSize/20
  ctx.shadowColor = "rgba(0, 0, 0, .2)"
  drawText(contentArr, opt.contentMarginLR, opt.contentMarginTB+opt.logoSize+opt.paragraphsMarginBottom)

  ctx.font = '700 '+opt.smallFontSize+'px '+opt.fontFamily
  ctx.fillText(name, opt.contentMarginLR+opt.logoSize+opt.smallFontSize, opt.contentMarginTB+opt.logoSize/2);
  ctx.font = '200 '+opt.smallFontSize+'px '+opt.fontFamily
  ctx.fillText(userId, opt.contentMarginLR+opt.logoSize+opt.smallFontSize, opt.contentMarginTB+opt.logoSize/2+opt.smallFontSize*1.2);

  const nowTime = getNowTime()
  ctx.textAlign = "right"
  ctx.fillText(nowTime, opt.width-opt.marginLR-opt.paddingLR, canvas.height-opt.marginTB-opt.paddingTB);

  await loadImage(logo, opt.contentMarginLR, opt.contentMarginTB)
  downloadImgFromCanvas(nowTime)
  return '![]('+canvas.toDataURL('image/png')+')'
}

module.exports = get_tweet_card;

Templater/生成哔哔卡片.md

1	<% tp.user.get_tweet_card(tp, `头像地址`, '用户名', '@id') %>

模板说明

头像应该是一张正方形图片，推荐 png，这样你可以在里面放圆形的头像或者什么。
头像图片 72*72 像素即可，用 https://c.runoob.com/front-end/59/ 转换为 base64 字符串，然后填入上方模板，注意要有引号
用户名，id 按需填写

使用方法

新建一个笔记，不要用已有笔记，否则你哭了我不管哄
选择插入此模板，填写内容，回车即可
如果是在电脑上，应该可以弹出保存对话框，把图片保存到你喜欢的位置
同时，这张图片被插入笔记中（别看源码，太长），把笔记删掉就可以了
在 Android 手机上，不会弹出下载，可以将笔记切换到阅读模式，然后用 Fooview 提取这张图片，实测很便捷。
苹果手机……我没有，我也不知道会怎样，该怎么做

自己的自己

怎么办怎么办，老鼠是笨蛋！
